Modular Carrier System

Single Motorcycle Carrier with Ramp Option

VH-55 RO

Single Motorcycles Carrier with Ramp

PRODUCT INFORMATION

Features

Specifications

What's Included
  • Fits any class III or IV hitch
  • Powder coat finish
  • Easily stores away
  • Boxed for UPS shipping
  • Reversible Rails
  • Dimensions
  • Model Number: VH-55 RO
  • Description: Single motorcycle carrier with ramp
  • Approx. Shipping Wt.: 94 lbs.
  • Carrying Capacity: 500 lbs.
  • Length of carrier rail: 71.5 in.
  • Width of carrier rail: 6.375 in.
  • Pin to center of rail: 21.5 in.
  • Length of ramp: 57.5 in.
  • Width of ramp: 5.5 in.
  • VH-55 Instruction Booklet
  • VH-55 RK Instruction Booklet
  • Anti-tilt lock bracket
  • 24 in. main tube
  • Four retractable tie down bars
  • One 6.375 in. x 71.5 in. carrier track
  • One wheel stop
  • Two reflectors
  • One ramp
  • One snap pin

MSRP: $727.99

Versahaul is the manufacturer and only sells to dealers. Versahaul suggests retail pricing only. Please contact your nearest dealer for additional price information. Prices subject to change without notice.

LIMITATIONS

Carrier

Hitch

Vehicle

Towing
The VH-55 carrier is designed to safely carry 500 lbs.

The motorcycle ramp limits bikes to tires under 5.5 in.

Helix, Reflex, Majestic, Gold Wing, and Burgman and similar scooters cannot be carried by a VH-55. Due to their length they cannot be weight centered on the rail. A VH-SPORT carrier is needed instead but further restrictions(weight/size) may apply. Calculator

Adventure Bikes are recomended for the stronger VH-SPORT due to the length and high center of mass.

Use the Minimum Ground Clearance Chart to determine the minimum ground clearance required to properly load your motorcycle or scooter onto a VH-55 or VH-55 DM carrier when using a VH-55 ramp.		 Most Class III hitches are rated for 500 lbs.

Most Class IV hitches are rated for 1000 lbs.

Low Hitch: The VersaHaul main tube extends out of the hitch at the same level. Hitches low to the ground will not work properly.

Recessed Hitches will shorten the length of the carrier tube.

For Solutions see our Risers and Extenders on the accessories page.		 Your hauling weight may be limited by your vehicle's capacity to carry a load.

Click here to find the Carrying Capacity of your vehicle.		 The VH-55 has a Class III hitch on the end of the carrier. It is limited to light-duty applications.

The max towing weight, regardless of your vehicle, is 3000 lbs.

PICTURES

Click on the item to see a larger picture.


Protected by US Patents: US D554,041 S; 20070052206
